| 원래 장소: | 중국 | 브랜드 이름: | TOPSKY |
|---|
|
상세 정보 |
|||
| 화면: | 12 인치 HIGH 표시등 LCD 스크린 | 잠금 장치: | 15 |
|---|---|---|---|
| 원격 무게: | 1.4kg | 상대습도: | 0 내지 95% |
| 이식성: | 간편한 운반과 신속한 배포를 위해 설계됨 | 보관 온도: | -45°C~65°C |
| 청각 장치 크기: | 210*100*100mm | 운반 무게: | <30kg |
| 너비: | 0.4m | 메인 엔진 중량: | 28kg |
| 가스 유량: | 1.0L 또는 고객 요구에 따라 설정합니다 | 바깥 커버: | 세탁 가능한 난연성 직물 |
| 무선제어 거리: | 500M | 회로 저항: | 14.7Ω |
| 스티어링 직경: | ≤2400mm | ||
| 강조하다: | Remote Control Fire-fighting Demolition Robot,Multi-functional Demolition Tool Extinguishing Robot,High Power Diesel Engine Rescue Robot |
||
제품 설명
This specialized robot replaces human operators in high-risk rescue environments including toxic contamination zones, structural collapse hazards, and high-radiation areas. The system enables remote-controlled demolition operations, concrete drilling and cutting, tunnel excavation, emergency response, furnace and kiln maintenance, and nuclear facility decommissioning while eliminating personnel exposure to danger.
| Parameter | Specification |
|---|---|
| Model | RXR-JM200D |
| Basic Functions | Multi-functional demolition tool head with cutting, expanding, squeezing, and crushing modes |
| Chassis Structure | ATV hydraulic tracked chassis |
| Power System | Four-stroke diesel engine (27kw) + hydraulic pump system |
| Dimensions | 3100mm (L) × 880mm (W) × 1850mm (H) |
| Travel Width/Height | ≤ 880mm / ≤ 1850mm (including water cannon system) |
| Weight | Approximately 1600kg (including crushing hammer) |
| Traction Force | ≥ 10000N |
| Tipping Force | ≥ 10000N |
| Maximum Speed | 0 - 3km/h, remote control with stepless speed variation |
| Climbing Ability | 58% (30°) |
| Remote Control Distance | 150m |
| Working Radius | 4.5m |
| Fuel Tank Capacity | 50L |
| Ground Clearance | 160mm |
| Obstacle Clearance | 200mm |
| Continuous Operation | 8 hours |
| Rescue Capability | Tipping tool for obstacle clearance; towing ring for transporting supplies and towing rescue vehicles |
